New Micro Mini 3G 4G GPS Tracking Device ,Build in Fuel Sensors，Complied with DLT rules,Special for Thai
Category:
BASIC TRACKER
Product description
Model No:ET800M
Product size : L72*W55*H24mm
Product description:
ET800M is designed by latest international industrial-class chip, dual-core structure. It is an entry model for DLT project ,which could support magnetic card reader ,It can support all kinds of vehicles ,as Taxi,bus,car, industrial Equipment etc. Compact small size ,it is easy hide and installation inside the vehicle.
Product Features :
 |
Real-Time Tracking You can set a specified time interval to upload location data. |
 |
Over-Speed Alarm Speed threshold can be set to realize over speed reminder. |
 |
Mileage Statistics Statistics driving mileage. |
 |
Track playback Can query historical vehicle trajectory data. |
 |
Remove Alarm Alarm prompt when equipment is removed. |
 |
Update Remotely Updating Maintenance Terminal Firmware Remotely. |
 |
Remote Management Function Software can be upgraded remotely through the GPRS network and through the FTP server. |
 |
Fuel monitor Monitor the fuel data of vehicles through voltage changes avoid to abnormal condition. |
Product Specifications:
|
ET800M |
|||
|
Start |
Cold start : 29 Seconds average |
Operating temperature |
-20°C to 70°C |
|
Warm Start: 28 Seconds average |
|||
|
Hot Start: 1 second,average |
|||
|
Humidity |
5% to 95% |
Standby battery |
450mAh/6H |
|
GPS sensitivity |
Tracking:－161 dB |
Position accuracy |
10m |
|
Cold start:－147 dB |
|||
|
Input voltage |
8-36V/DC |
Channels |
56 |
|
Accuracy |
Horizontal Position: Autonomous<2.5 |
LED indicator |
2 indicators showing GSM and GPS status |
|
Average Velocity: 0.1m/s |
|||
|
Time pulse signal: RMS 30ns |
|||
|
Time interval record |
1s |
GSM Module |
QUECTEL UC15-T |
|
Frequency band |
GMS850/900/1800/1900 UMTS850/2100 |
I/O port |
Power: PWR、GND |
|
Input: SOS、ACC、1 digital input |
|||
|
Output: Relay or Buzzer |
|||
|
Power Consumption |
1.5W |
Weight |
0.515kgs |
|
Memory |
2040 location/8MB/34H |
Speeding record discrepancy |
+ / - 1km per hour |
APPLICATIONS AREAS
 |
 |
 |
|
Logistic |
Vehicle Tracking |
Car Rental |
