New Micro Mini 3G 4G GPS Tracking Device ,Build in Fuel Sensors，Complied with DLT rules,Special for Thai
Category:
BASIC TRACKER
Product description
Model No: ET800D
Product size : L112*W98*H38mm
Product description:
ET800D has 3G &4G version, it is "more than a tracker ", which suitable for even industrial vehicle like Fuel truck, taxi, bus etc. By using the expansion ports, that allow user connect others accessories to get extra information on vehicle side, such as camera, RFID reader, door sensor, printer, oil sensor, and etc.
Product Features :
 |
Real-Time Tracking You can set a specified time interval to upload location data. |
 |
Over-Speed Alarm Speed threshold can be set to realize over speed reminder. |
 |
Mileage Statistics Statistics driving mileage. |
 |
Track playback Can query historical vehicle trajectory data. |
 |
Remove Alarm Alarm prompt when equipment is removed. Fuel monitor |
 |
Update Remotely Updating Maintenance Terminal Firmware Remotely. |
 |
Remote Management Function Software can be upgraded remotely through the GPRS network and through the FTP server. |
 |
Fuel monitor |
Product Specifications:
| ET800D | |||
|
Frequency band |
LTE-FDD B1/B3/B5/B8 |
Humidity |
5% to 95% |
|
LTE-TDD:B34/B38/B39/B40/B4 |
Channel |
56 |
|
|
1GSM: 900/1800MHz |
Memory |
1024 location/ 192kb |
|
|
Position accuracy |
10m |
Operating temperature |
-20°C to 70°C |
|
Start |
Cold start : 29 Seconds, average |
Input voltage |
8-36V/DC |
|
Warm Start:28 Seconds, average |
GPS sensitivity |
Tracking:－161 dB |
|
|
Hot Start:1 second,average |
Cold start:－147 dB |
||
|
Time interval record |
1S |
LED indicator |
2 indicators showing GSM and GPS status |
|
Accuracy |
Horizontal Position: Autonomous<2.5 Average
|
I/O port
|
Power: PWR、GND； |
|
Velocity: 0.1m/s, Time pulse |
|
||
|
Signal: RMS 30ns |
Output: Relay |
||
|
Weight |
1kg |
data bus: for Peripherals |
|
|
power consumption |
3W |
Standby battery |
800Mah |
|
Sending information through mobile network |
1 time per min |
Speeding record discrepancy |
+ / - 1km per hour |
APPLICATION AREAS
 |
 |
 |
|
Logistic |
Vehicle Tracking |
Fleet Management |
