360 Degree Surround Birdview Car Panoramic System With HD Night Vision Function
Category:
360 Panoramic Camera
Product description
360 Degree Camera
Product description:
Our 360 degree car panoramic image driving assistance system supports 2D/3D screen switching, and supports large and private vehicles, with 360 degree image, whether drive or reverse ,it helps drivers to drive safer.
Product Features :
Four 190 degrees ultra wide fish-eye cameras.
Seamless video merging based on dual core ARM CPU and hardware high efficiency acceleration engine.
Arbitrary and dynamic 3D mode view angle switching for better surrounding environment observation.
Independent Fish-eye calibration parameter and algorithm for each camera.
Pixel statistic engine for brightness balance among four channels real-time outside cameras.
High video recording resolution up to 1080p.
Specifications:
|
MODEL |
YX901-2D |
YX906-2D |
YX909-2D |
YX911-3D |
YX916-3D |
|
Video output method |
CVBS |
LVDS(include 7 or 9"monitor) |
CVBS, AHD, HDMI VGA |
||
|
Master chip |
Quad-core ARM Cortex™-A7 1.2GHZ |
Quad-core ARMCortex-A5364 |
|||
|
video save |
A total of four channels, each channel works independently |
||||
|
Save as a video image |
|||||
|
Bird's-eye view panorama four channels to save video images |
|||||
|
Camera sensor |
Sony225 or domestic |
1080P module |
|||
|
wide angle lens |
180 degree |
200 degree |
|||
|
Resolution |
1024*600 |
1280*720，1920*1080 |
|||
|
Video format |
MP4 |
MP4 |
|||
|
Support memory card |
Maximum 128G |
||||
|
Input voltage |
Host 9V-16V |
Host 9V-36V |
|||
|
display |
without |
without |
1024*600 |
without |
|
|
Video resolution |
2560*1440 |
2560*1440 |
2560*1440 |
1920*1080 |
|
|
Video mode |
Power on, vibrate to trigger recording |
Start recording, delay recording |
|||
|
Loop recording |
Automatic loop overwriting after recording full files |
||||
|
Live preview |
Quad machine supports single screen, four screens, steering display, bird's eye view panorama |
||||
|
remote control |
Wireless infrared remote control menu settings |
||||
|
picture capture |
Capture the current playing picture of the corresponding selection window and save it as a picture in BMP format |
||||
|
Instantaneous current at start up |
400mA |
||||
|
stand-by current |
Standby 10mA |
||||
|
Video current |
450 mA |
||||
|
Quiescent Current |
less than 5mA |
||||
APPLICATION AREAS
