4G T-Box MDVR OBD Tracking Device Diagnostic Tools
Category:
OBD GPS
Product description
Model No:YX-M501
Product size : L123mm*W80mm*H35mm
Product description:
YX-M501 is a super version car OBD intelligent terminal device. It can compatible with passenger cars, commercial vehicles, new energy vehicles OBD terminal function. According to the demand expansion device functions, including 4G module, support BD/GPS dual mode, Six-axis of gyroscope, 2 CANS, 4 input and 4 output, TF card, SOS, RS485/RS232 etc.
Product Features ：
 |
Real-Time Tracking The device can receive and transmit data in the coverage of 4G, 3G and 2G network. |
 |
4G LTE Communication The device can receive and transmit data in the coverage of 4G, 3G and 2G network. |
 |
Obtain OBD Data Mileage VIN code Vehicle failure Speed Speed Fuel consumption. |
 |
Driving Behavior Analysis (Advanced) Receive alerts when any of 7 kinds of dangerous driving behavior is detected. |
 |
Maintenance data Meter Mileage Remaining Fuel Oil Level Coolant Fluid Level Tire Pressure Brake Pad Wear. |
 |
Multiple Alerts Instant alerts for atypical events such as low voltage , speeding, abnormal driver behaviors, etc. |
 |
Monitor Vehicle Status Doors, Windows, Turn Signals, Headlights, Accelerator, Brakes, Seat Belts, Gears, Air Conditioning, Trunk Status. |
 |
Remote Management Function Software can be upgraded remotely through the GPRS network and through the FTP server. |
Product Specifications:
|
Technical Item |
Technical Specifications |
|
|
Storage |
SD Card |
Double SD Card (Maximum Of Single Card Is 256G) |
|
Operating System |
Operating System |
Linux |
|
Control Mode |
Network,Phone APP |
|
|
Video Recording
|
Video and audio compression format |
Video H.264,g771A |
|
Image Resolution |
720P |
|
|
Video Mode |
Power on/manual/timing/plan/alarm recording events |
|
|
ACC off , time-lape video |
Delay Parameter Range；10-65535s, Default:300s |
|
|
Real-time Video |
Support |
|
|
Mirror Video |
Support |
|
|
Alarm Video |
Support |
|
|
Backup Video |
Support |
|
|
Audio
|
Input |
Maximum 4-channel audio |
|
Output |
2-channel audio |
|
|
Video |
Standard Definition Input |
4-channel D1 |
|
AHD 720P |
4-channel 720P |
|
|
Output |
4-channel CVBS |
|
|
Video Signal |
PAL |
|
|
Network |
2G/3G/4G |
4G TD-LTE/4G FDD-LTE/3G TD-SCDMA/3GWCDMA/3GCDMA2000/2G(GSM) |
|
WIFI |
802.11b/g/n/(Optional) |
|
|
Display |
Screen display |
4 screen display |
|
Playback |
Playback Channel |
Support local multi-channel synchronous playback , PC software remote single-channel playback |
|
Browse Mode |
Time , Channel |
|
|
Note:Maximum 4-channel 720P HD camers |
||
APPLICATION AREAS
 |
 |
 |
|
Fleet Management |
Logistic |
Commercial Cars |
