4G Mobile DVR DMS Driver Fatigue ADAS GPS All In One Device
Category:
MDVR+ADAS+DMS
Product description
Model No: YX02T
Product size: L161mm*W124mm*H41mm
Product description:
YX02T integrates ADAS advanced driver assistance system and DSM driver monitoring system, and supports functions such as audio and video recording, SD card storage, driving data recording, platform uploading, two-way calling, and real-time monitoring.
Product Features :
 |
HD live video Support 4-channel 720P high-definition video real-time storage and upload . |
 |
remote intercom Support handhold intercom or hands-free intercom. |
 |
Linkage alarm Support signal linkage trigger alarm and triple emergency linkage alarm, when danger occurs, it will upload video or photo automatically. |
 |
Support Extension ports It can be connected to peripherals such as oil poles, advertising screens, broadcast stations, etc. |
 |
Compliant with multiple protocols Refer to JT/T 794-2019, JT/T 808-2019 JT/T 1076-2016, JT/T 1078-2016 etc. |
 |
Support Large capacity storage it can support 2 *sd card for circular storage , a single card support up to 128G. |
 |
wifi connection External or built-in WiFi module, connect to advanced assistant, set query parameters, live video in real time. |
 |
ADAS+DSM Support active safety driving assistance system (ADAS+DSM) & driver fatigue monitor system . |
Product Specifications:
|
Technical Item |
Technical Specifications |
|
|
Storage |
SD Card |
Double SD Card (Maximum Of Single Card Is 256G) |
|
Operating System |
Operating System |
Linux |
|
Control Mode |
Network,Phone APP |
|
|
Video Recording
|
Video and audio compression format |
Video H.264,g771A |
|
Image Resolution |
720P |
|
|
Video Mode |
Power on/manual/timing/plan/alarm recording events |
|
|
ACC off , time-lape video |
Delay Parameter Range；10-65535s, Default:300s |
|
|
Real-time Video |
Support |
|
|
Mirror Video |
Support |
|
|
Alarm Video |
Support |
|
|
Backup Video |
Support |
|
|
Audio
|
Input |
Maximum 4-channel audio |
|
Output |
2-channel audio |
|
|
Video |
Standard Definition Input |
4-channel D1 |
|
AHD 720P |
4-channel 720P |
|
|
Output |
4-channel CVBS |
|
|
Video Signal |
PAL |
|
|
Network |
2G/3G/4G |
4G TD-LTE/4G FDD-LTE/3G TD-SCDMA/3GWCDMA/3GCDMA2000/2G(GSM) |
|
WIFI |
802.11b/g/n/(Optional) |
|
|
Display |
Screen display |
4 screen display |
|
Playback |
Playback Channel |
Support local multi-channel synchronous playback , PC software remote single-channel playback |
|
Browse Mode |
Time , Channel |
|
|
Note:Maximum 4-channel 720P HD camers |
||
APPLICATION AREAS
 |
 |
 |
| Fleet Management | Mining Truck | Vehicle Tracking |
